878HL-2

Model: AMS-878HL-1437
Please log in to see your price
Dealer locator
Omnidirectional dynamic desk top microphone with locking push to talk switch
About This Product

Description:

The Astatic Model 878HL is a duel impedance, omnidirectional dynamic desk microphone offering modern styling and features in a rugged Cycolac housing for all industrial and commercial public address and paging applications. The Model 878HL has a slide switch for low or high impedance selection. The wide band frequency response is smooth and peak free, with a slight rise above 2K Hz to give that "natural" highly intelligible sound. The microphone and relay switching is accomplished with long life DPDT professional leaf switches and choice of either a simple push-to-talk bar with locking capabilities, or lift-to-talk operation, to give years of dependable, trouble free performance. The lift-to-talk operation can be disabled with a slide switch located under the microphone base. The 878HL is manufactured to take normal abuse and retain its performance over a long life. Four molded "feet", non-skid, non-marring, permanently resilient, are located under the zinc die cast base. Supplied with 2.1m (7 ft.) of four conductor, two shielded cable, the Model 878HL microphone circuit is wired normally open. Available in black.

Element: Dynamic

Pattern: Omnidirectional

Frequency Response: 50 to 12,000 Hz

Output Level: HiZ: -55dB (0dB = 1 volt / microbar) -151 dB EIA

LoZ: -58 dB (0dB = 1mw / 10 microbars) -76 dB (0dB = 1 volt / microbar) -152 dB EIA

Impedance: HiZ: 40,000 ohms, matches 100K ohms or greater

LoZ: 400 ohms, matches 125 to 1000 ohms

Switch: Control: DPDT professional long life leaf switches operated with a simple push-to-talk operation.

Impedance: DPDT slide switch located on underside of the microphone

Cable: 2.1m (7 ft.) of heavy duty four conductor (two shielded) cable

Dimensions: 238mm (9-3/8") high; 110mm (4-11/32") wide 148mm (5-27/32")deep

Weight: 687 grams (24-1/4 oz.)

Finish: Durable molded Cycolac in black with die cast base painted in a complimentary color
