Inputs and outputs unbalanced (75 ohms via BNC sockets)
Highly sensitive inputs for regenerating unclean and smooth signals
High output voltages for bridging large distances
Output impedance can be switched from 75 ohms to 50 ohms via jumpers for operating dirty WCLK inputs
Switchable via jumpers to AES-3id
Switchable via jumpers to “Superclock 256 Fs”
optional MULTI-SYNC UNIT
Inputs and outputs unbalanced (75 ohms via BNC sockets)
Highly sensitive inputs for regenerating unclean and smooth signals
High output voltages for bridging large distances
Output impedance can be switched from 75 ohms to 50 ohms via jumpers for operating dirty WCLK inputs
Switchable via jumpers to AES-3id
Switchable via jumpers to “Superclock 256 Fs”
digital distribution amplifier for WCLK or AES-id signals.
2 inputs and 16 outputs.
Two identical modules with 1 input and 8 outputs.
Switched internally, 1 in 8 is also possible.
Inputs and outputs unbalanced, impedance 75 ohms via BNC sockets.
Highly sensitive inputs to regenerate dirty and blurred signals
High output voltages for bridging large distances.
Output impedance switchable from 75 ohms to 50 ohms via jumpers.
Can be switched to “Superclock 256 Fs” via jumpers.
